Technologies

BB 386

The BB386EVO system takes the oversized bottom bracket design concept, which was successfully introduced by Wilier Triestina in the Cento1 model and subsequent variations, to its next evolution. To obtain an unprecedented stiffness at a crucial point of the frame, we have devised an innovative system that can perfectly incorporate an ultra-stiff crank into an ultra-stiff frame. The traditional BB30 system proved inadequate because it requires a frame with a 68 mm box, which is too narrow to deliver the degree of stiffness that we wanted. With this in mind, we developed the new standard BB386EVO in collaboration with FSA, which pairs a carbon crank with a longer 30 mm spindle and a wider 86.5 mm bottom bracket box.

Technologies

razor edge design

The Razor Edge Design overlaps top and down tube at at the head tube to form a single, integrated and reinforced unit. Combined with the unique lines of the specially structured fork, we’ve optimized lateral stiffness and front end stability for quick accelerations as well as smooth, precise handling speed.

Technologies

THT

Tapered Head Tube provides increased stiffness to the bottom of the head tube for enhanced steering and stability.

Technologies

LIT

We’ve also leveraged LIT (Large Inflation Tube) technology in the making of the Cento1 Superleggera. Our prepreg carbons benefit from even higher and more uniform compaction through the use of industrial, high pressure bladders. The bladders expand from within the frame’s tubing, pushing against the inner walls of the tubes as the frame mould exerts opposing pressure from the outside. The combined compaction- forces result in a precision, lower-void construction and consistent wall thickness of the tubes throughout the frame’s construction. More traditional carbon manufacturing processes fail to optimally compact a composite, resulting in varied wall thicknesses, or voids (undesirable resin deposits), along a frame’s tubing that compromise structural integrity. That could translate into reduced longevity and strength. So the advantages of the Cento1 SL’s construction are obvious: increased capacity to handle stresses, optimal torsional stiffness, and unparalleled responsiveness.

Technologies

SEI special elastic infiltra

Zero.7 marks the implementation of an exclusive new Wilier Triestina technology: S.E.I. Film (Special Elastic Infiltrated). The injection of a proprietary viscoelastic film between layers of carbon increases vibration absorption and impact resistance, therefore making the frame safer and more comfortable. This new material has already been widely tested in the aeronautical and automotive industries with excellent results. It is now being applied in the construction of bicycles for the first time.

Technologies

smooth reardesign

This special technology is applied on the rear arms. It dampens and dissipates vibrations over all kinds of road surfaces.
